24v 5000a air cooling 415V 3 phase igbt hard chrome plating rectifier

Features:

• Our 24v 5000a air cooling 415V 3 phase igbt hard chrome plating rectifier uses famous brand components and international advanced full bridge inverter technology of precision machining, so that the performance of the whole 24v 5000a air cooling 415V 3 phase igbt hard chrome plating rectifier is stable,quality is more reliable.
• Whole 24v 5000a air cooling 415V 3 phase igbt hard chrome plating rectifier has the function of over voltage, over current, over temperature, short circuit, equal and automatic protection alarm function and soft start function. And can be equipped with time control and computer interface.
• DC output waveform is high frequency square waveform, ripple factor less than 1%, can increase plating, refuse passivation, enhance the gloss of the plating coating surface and the core of the dark corner of plating coating. And can reduce the loss of raw materials, to achieve a variety of special requirements of electroplating industry.

Method:

• 24v 5000a air cooling 415V 3 phase igbt hard chrome plating rectifier adopts air cooling/water cooling design, easy to install. With remote control device, simple operation. Can switch off the machine when loading, reduce cumbersome procedures of adjustment.

24v 5000a air cooling 415V 3 phase igbt hard chrome plating rectifier advantage of small size and energy saving:

• Small size, light weight, the whole 24v 5000a air cooling 415V 3 phase igbt hard chrome plating rectifier use a full range of anti-corrosion technology, enhanced the product’s anti corrosion ability, extend the service life.
• High efficiency, energy saving, work efficiency can reach more than 90%, any voltage current ratio is always linear matching. Eliminating the need for traditional rectifiers regulator and the main transformer loss, energy saving in more than 35%, greatly reducing the electro plating cost, which is the most sensible choice for surface treatment plating machine industry

• 24v 5000a air cooling 415V 3 phase igbt hard chrome plating rectifier specification and parameter:
  Plating rectifier Input voltage	three phase 415V
  Output voltage	0~24v adjustable
  Output current	0-5000A adjustable
  Voltage stability	≤1%
  Current stability	≤1%
  Ripple factor	1%-2%
  Efficiency	≥90%
  Stabilization mode	Current stabilization/Voltage stabilization (Switchable easily)
  Adjustment range	Voltage/Current from 0-100% continuously adjustable within rated range
  Cooling system	Air cooling
  Control method	local panel control
  Display contents	Voltage meter/Current meter/Working/Over temp/Error, etc..
  Protection method	Input over-voltage/Under-voltage/Over current/Output short/Over heating self protection etc..
  Operating temperature	-20-50℃
  Ambient temperature	-30-65℃
  Ambient humidity	≤90%
